user manual
LMS-D24/26
LMS-D2X user manual
Page 7
Introduction
The Turbosound LMS series of loudspeaker management systems represents the current state-of-
the-art in digital electronics. The LMS-D24/26 are compact and powerful DSP based audio-
processing units designed for use with Turbosound loudspeaker systems and associated bass
enclosures, combining the functions of multiple conventional products in a compact 1U high 19”
rack unit. To achieve this the LMS-D26 has 2 inputs and 6 outputs (the LMS-D24 features four
outputs), which are configured by different factory presets to allow use with a variety of systems.
The units are designed to provide specific equalisation and crossover points aimed at optimising
the performance of these Turbosound loudspeaker systems. In addition, limiters, delays eq, gain,
polarity, and crossover filter controls are accessible to the user in order to match specific operation
environments. The LMS series crossovers are designed for quick setup and adjustment via easy-to-
use front panel controls.
Features
• Minimal signal path design, providing exceptional audio quality with carefully optimised
processing and high performance converters for a full >111dB dynamic range, 96kHz
sampling rate and minimal filtering. Audio-grade capacitors are used in the analogue signal
path.
• Sonically superb ADC / DAC combination; a carefully matched pairing of the best devices
from Burr Brown and Wolfson.
• Newly released family of Analogue Devices SHARC DSP.
• Extended bandwidth; 96kHz sampling frequency provides for a nominally flat response to
40kHz.
• Front panel parameter rotary encoder provides a familiar and easy to use control format
with all filter information displayed simultaneously on a backlit LCD display.
