TURNTIDE Hub 7 - Powering Hub Only; Connecting Internet

9
© Turntide Technologies. Condential. All Rights Reserved. DOCT00369-082321 Last Modied: 2023-03-09
3.3.3. Powering Hub Only
12 VDC - 57 VDC
3.4. Connecting Internet
The Turntide Hub requires an active internet connection to connect to the Turntide Cloud. An ethernet
connection to an active internet line is required at the installation location to be connected to the Turntide
Hub. When using a local LAN connection the below port congurations are required to be completed by the
Network Administrator.
List of Ports to be Opened by IT
Destination Protocol Port
Required Egress Turntide Cloud MQTT TCP/8883
Required Egress Turntide Cloud SST TCP/3199
Required Egress Turntide Cloud HTTPS TCP/443
