TURNTIDE Hub 7 - USB Network; What Can be Connected; How to Connect; Limitations; Cable Specifications

13
© Turntide Technologies. Condential. All Rights Reserved. DOCT00369-082321 Last Modied: 2023-03-09
Termination type
Daisy Chain
Maximum cable length
1200 m (4000 ft)
Maximum devices
Electrical load and protocol dependent
4.3. USB Network
4.3.1. What Can Be Connected
The USB ports on the Turntide Hubs can be used to connect Turntide VRF Adapters and USB adapters.
4.3.2. How to Connect
USB devices can be plugged directly into the available USB ports on the optional 7 port USB Hub expander.
When using the Turntide enclosure, the HUB 7 can support up to 4 USB devices. IF additional USB devices are
needed they should be plugged into the optional 7 port USB Hub available from Turntide.
4.3.3. Limitations / Cable Specications
Allowed cable types USB
Maximum cable length 5 m (16 ft)
Maximum devices 1 per a USB port
