Manual 4804 Rev C p/n 004804 0000
KLRC-40 KLRC-75 KLRC-125 KLRC-200 KLRC-300 KLRC-525 KLRC-526 KLRC-950 KLRC-951
Speed RPM
1750 1750 1750 1750 1750 1750 1450 1150 860
Drive Type Direct Direct Direct Direct Direct Direct Belt Direct Belt
Standard Motor
HP 5 5 10 15 25 50 40 100 75
kW 3.8 3.8 7.6 11.4 19 38 30.4 74.6 55.9
Sealant Liquid Required
(at 60°F w/ no sealant recovery)
GPM 5 5 7 8 12 18 18 26 26
L/min 19 19 26 30 45 70 70 98 98
Sealant Liquid Required
(at 60°F w/ partial sealant recovery)
GPM 33446991313
L/min 11 11 15 23 30 45 45 49 49
Liquid required to ¿ ll a Full Sealant
Recovery (FSR) System
US gal 4.6 5 6.3 7.5 9 24 24 - -
Liters 18 19 24 28 34 91 91 - -
Cooling Fluid at 60°F required for HX*
GPM 5 5 10 15 25 50 50 52 52
L/min 19 19 28 57 95 190 190 197 197
Sealant Liquid Connections NPT 1/2" 1/2" 3/4" 1" 1" 1-1/4" 1-1/4" 1-1/2" 1-1/2"
Inlet/Outlet Flange
**ANSI
150 Class
1-1/2" 1-1/2" 1-1/2" 2" 2" 3" 3" 4" 4"
Overall Length
in 22.6 24.1 28.1 29.7 33.6 41 41 56.5 56.5
mm 573 613 713 754 852 1041 1041 1435 1435
Overall Height
in
12.6 12.6 16 19.1 19.1 23.5 23.5 30.56 30.56
mm 321 321 406 486 486 597 597 776 776
Width
in 11.9 11.9 12.8 16.9 16.9 18.9 18.9 25.32 25.32
mm 302 302 324 429 429 479 479 643 643
Shaft Height
in 6.5 6.5 6.9 8.3 8.3 9.8 9.8 12.59 12.59
mm 165 165 175 210 210 249 249 320 320
Weight, Net Pump only
lbs 155 200 255 360 405 800 800 1590 1590
kg 70 91 116 163 184 363 363 721 721
* The HX cooling À uid À ow·rates are based on sealant À uid entering the HX at 80°F and exiting at 65°F. Cooler or warmer À uid than 60° will effect the À ow rate.
** (ANSI) American National Standards Institute
06
SPECIFICATIONS
