PARTS LIST – CAST IRON 40 AND 75 KLRC ASSEMBLY
ITEM
NO.
PART DESCRIPTION QTY
10 End Casing NDE 1
20 End Casing DE 1
30 End Plate DE 1
40 End Plate NDE 1
50 Center Housing 1
60 Impeller DE 1
70 Impeller NDE 1
80 Impeller Housing DE 1
90 Impeller Housing NDE 1
100 Shaft 1
110 Bearing Housing 2
120* Oil Seal 2
130** Grease Fitting 2
140 Cap, Bearing Housing DE 1
150 Cap, Bearing Housing NDE 1
160 Tie-Rod DE 4
170 Tie-Rod NDE 4
180 DE Impeller Nut (LH) 1
185 DE Impeller Lock Nut (LH) 1
190 NDE Impeller Nut (RH) 1
195 NDE Impeller Lock Nut (RH) 1
210 Flinger 2
220 Bearing Spacer 1
230 Shaft Seal Spacer 1
240** Shaft Seal, LR 2
250* Attenuation Valve, 1/4 NPT 1
260** Viton O-Ring 2
270** Ball Bearing, Double Row 1
280** Ball Bearing, Single Row 1
290** Locknut Bearing 1
300 DE Impeller Key 1
310 NDE Impeller Key 1
320** Drive Shaft Key 1
330 Bearing Housing Hex Head Cap
Screw
8
340 Bearing Housing Cap Hex Head
Cap Screw
6
ITEM
NO.
PART DESCRIPTION QTY
350** End Plate Hex Socket Cap
Screw
4
360 Tie-Rod Hex Nut 8
370 Tie-Rod Plain Washer 8
380 Bearing Housing Lock Washer 8
390 Bearing Housing Cap Lock
Washer
6
400 Attenuation Valve Hex Head
Bushing
1
410* Center Housing PPG, CTSK 2
420 Drain Pipe Plug, Square 3
430* Drain Pipe Plug, Hex Socket 3
440* Shaft Seal PPG, Hex Socket 2
460* DE End Casing PPG, CTSK 1
