Parts Lists and Assembly Drawings
Manual 4804 Rev C p/n 004804 0000
PARTS LIST – 950 KLRC ASSEMBLY
ITEM
NO.
PART DESCRIPTION QTY
10 End Casing DE 1
20 End Casing NDE 1
30 End Plate DE 1
40 End Plate NDE 1
50 Center Housing 1
60 Impeller DE 1
70 Impeller NDE 1
80 Impeller Housing DE 1
90 Impeller Housing NDE 1
100 Shaft 1
110 Bearing Housing 2
120 Lip Seal 2
130* Grease Fitting 2
140 End Cap DE 1
150 End Cap NDE 1
160 Crossover Pipe 1
170 Tie-Rod DE 8
180 Tie-Rod NDE 8
190 Impeller Lock Nut, LH, M80 x 1.5 1
200 Impeller Nut, LH, M80 x 1.5 1
210 Impeller Lock Nut, RH, M80 x 1.5 1
220 Impeller Nut, RH Threaded 1
230 Flinger 2
240 Bearing Spacer 1
250 Ring Gasket, 4" 2
260 Mechanical Seal 2
270 Ball Valve, 0.75" 1
280 O-Ring 2
290 Bearing 2
300 Locknut Bearing 1
310 Impeller Key 2
320 Square Key, 0.5" x 3.25" 1
330 Hex Bolt, 0.625"-11 x 2.5" 16
340 Hex Bolt, 0.625"-11 x 2" 8
350 Hex Bolt, 0.375"-16 x 1.25" 8
ITEM
NO.
PART DESCRIPTION QTY
360* Hex Socket Cap Screw
,
0.375"-16 x 1"
2
370 Hex Nut, 0.75" 16
380 Flat Washer, 0.75" 16
390 Lock Washer, 0.625" 8
400 Lock Washer, 0.375" 8
410 Hex Reducing Bushing 1
420 Flat Washer, 0.625" 16
430* Pipe Plug, Square Socket, 1.25" 2
440 Pipe Plug, Hex Socket, 0.5" 12
450* Pipe Plug, Square Socket, 1.5" 1
460 Nipple, 1.5" 1
470* Nipple, 0.75" 1
480 Elbow, 1.5" NPT 1
490 Street Elbow 1
500 Hex Nut, 0.625" 16
* Items Not Shown
