Tuthill KLRC40 - Parts List - Cast Iron 125-525 KLRC Assembly

37
Parts Lists and Assembly Drawings
Manual 4804 Rev C p/n 004804 0000
PARTS LIST – CAST IRON 125-525 KLRC ASSEMBLY
ITEM
NO.
PART DESCRIPTION QTY
10 End Casing DE 1
20 End Casing NDE 1
30 End Plate DE 1
40 End Plate NDE 1
50 Center Housing 1
60 Impeller DE 1
70 Impeller NDE 1
80 Impeller Housing DE 1
90 Impeller Housing NDE 1
100 Shaft (LH Threaded) 1
110 Bearing Housing, GRSBL
Bearing
2
120** Bearing Housing Oil Seal 2
130** Bearing Housing Grease Fitting 2
140 End Cap DE, GRSBL 1
150 End Cap NDE, GRSBL 1
160 Crossover Pipe 1
170 Tie-Rod DE 8
180 Tie-Rod NDE 8
190 Impeller Lock Nut, LH Threaded 1
195 Impeller Nut, LH Threaded 1
200 Impeller Lock Nut, RH Threaded 1
205 Impeller Nut, RH Threaded 1
220 Flinger 2
230 Bearing Spacer 2
240 Shaft Seal Spacer 2
250** Crossover Flange Gasket 2
260** Shaft Seal, LR 2
270 Attenuation Valve 1
280** Bearing Housing O-Ring 2
290** Bearing, Double Row Angular
Contact
1
300** Bearing, Single Row Conrad 1
310** Locknut Bearing 1
320 DE Impeller Key 1
330 NDE Impeller Key 1
340** Drive Shaft Key 1
350 Crossover Stud 8
ITEM
NO.
PART DESCRIPTION QTY
360 Bearing Housing Hex Head Cap
Screw
8
370 Bearing Housing Cap Hex Head
Cap Screw
6
380** End Plate Hex Socket Cap
Screw
4
390 Tie-Rod/Crossover Hex Nut 24
400 Tie-Rod/Crossover Plain Washer 24
410 Bearing Housing Lock Washer 8
420 Bearing Housing Cap Lock
Washer
6
430 Attenuation Valve Hex Head
Bushing
1
440* Center Housing PPG, CTSK 2
480* Vacuum Relief Valve PPG, Hex
Socket
1
500 Sealant Inlet Pipe Nipple 1
510 Attenuation Pipe Nipple 1
520 Sealant Inlet Elbow, 90° 1
530 Attenuation Elbow, 90° 1
* Items Not Shown
** Recommended Spare Parts
