Tuthill KLRC40 - Parts List - Stainless Steel 40 and 75 KLRC Gasketed Assembly

35
Parts Lists and Assembly Drawings
Manual 4804 Rev C p/n 004804 0000
PARTS LIST – STAINLESS STEEL 40 AND 75 KLRC GASKETED ASSEMBLY
ITEM
NO.
PART DESCRIPTION QTY
10 End Casing NDE 1
20 End Casing DE 1
30 End Plate DE 1
40 End Plate NDE 1
50 Center Housing, Gasketed 1
60 Impeller DE 1
70 Impeller NDE 1
80 Impeller Housing DE, Gasketed 1
90 Impeller Housing NDE,
Gasketed
1
100** Gasket Set, 0.015" Thick PTFE 1
110 Shaft 1
120 Bearing Housing 2
130** Oil Seal 2
140** Grease Fitting 2
150 Cap, Bearing Housing DE 1
160 Cap, Bearing Housing NDE 1
170 Tie-Rod DE 4
180 Tie-Rod NDE 4
190 DE Impeller Nut (LH) 1
195 DE Impeller Lock Nut (LH) 1
200 NDE Impeller Nut (RH) 1
205 NDE Impeller Lock Nut (RH) 1
220** Flinger 1
230 Bearing Spacer 2
240** Shaft Seal, LR 2
250* Attenuation Valve, 1/4 NPT 1
260** Viton O-Ring 2
270** Ball Bearing, Double Row 1
280** Ball Bearing, Single Row 1
290** Locknut Bearing 1
300 DE Impeller Key 1
310 NDE Impeller Key 1
320** Drive Shaft Key 1
330 Bearing Housing Hex Head Cap
Screw
8
340 Bearing Housing Cap Hex Head
Cap Screw
6
ITEM
NO.
PART DESCRIPTION QTY
350** End Plate Hex Socket Cap
Screw
4
360 Tie-Rod Hex Nut 8
370 Tie-Rod Plain Washer 8
380 Bearing Housing Lock Washer 8
390 Bearing Housing Cap Lock
Washer
6
400 Drain Pipe Plug, Square 3
405 Center Housing PPG, CTSK 2
410 Impeller Housing PPG, Hex
Socket
2
430 Shaft Seal PPG, Hex Socket 2
440 DE End Casing PPG, CTSK 1
445 Attenuation Valve Hex Head
Bushing
1
* Items Not Shown
** Recommended Spare Parts
