Tuthill PD Plus 1215 - Page 13

13
Figure 5 - Location of oil fill, drain, level gauges and cooling connections
NON-DRIVE END
DRIVE END
DRIVE END DRIVE END
DRIVE END
SIDE SIDE
VIEW A-A
VIEW A-A
VIEW A-A
TOP TOP
19/55 SERIES
HORIZONTAL FLOW
69 SERIES
VERTICAL FLOW
82/86 SERIES
VERTICAL FLOW
66 SERIES
HORIZONTAL FLOW
OIL
PRESSURE
GAUGE
OIL
PRESSURE
GAUGE
OIL FILL PLUG
(1) EA END PLATE
OIL FILL PLUG
(1) EA END PLATE
OIL FILL PLUG
(1) EA END
PLATE
OIL FILL PLUG
(1) EA END PLATE
ALTERNATE
DRIVE SHAFT
LOCATION
BREATHER
(1) EA END COVER
ALTERNATE DRIVE
SHAFT LOCATION
MAGNETIC
DRAIN PLUG
(1) EA END PLATE
MAGNETIC
DRAIN PLUG
(1) EA END PLATE
MAGNETIC
DRAIN PLUG
(1) EA END PLATE
MAGNETIC
DRAIN PLUG
(1) EA END PLATE
COOLING WATER
INLET 1” NPT
COOLING
WATER
INLET 1/4” NPT
COOLING WATER
INLET 1/4” NPT
COOLING WATER
OUTLET 1/4” NPT
COOLING WATER
OUTLET 1/4” NPT
OIL
PRESSURE
GAUGE
OIL
PRESSURE
GAUGE
OIL FILTER
OIL FILTER
OIL COOLER
OIL COOLER
OIL COOLER
OIL PUMP
OIL PUMP
OIL FILTER
OIL FILTER
OIL PUMP
OIL PUMP
COOLING WATER
OUTLET 1” NPT
OIL LEVEL
SIGHT GAUGE
OIL LEVEL
SIGHT GAUGE
OIL LEVEL
SIGHT GAUGE
OIL LEVEL
SIGHT GAUGE
VENT HOLE ON
BOTTOM OF BLOWER IS
OPEN TO ATMOSPHERE
(TYP EA END PLATE)
VENT HOLES ARE
PLUGGED. (6) 1/2” NPT EA
END PLATE. TO PURGE,
CONNECT LINE TO
(1) HOLE AND LEAVE
OTHER (5) PLUGGED
ON EA END PLATE.
VENT
HOLES ARE
PLUGGED.
(6) 1/2” NPT
EA END PLATE.
TO PURGE,
CONNECT LINE TO
(1) HOLE AND
LEAVE OTHER (5)
PLUGGED ON EA
END PLATE.
VENT HOLES ARE
PLUGGED.
(6) 1/2” NPT EA
END PLATE.
TO PURGE, CONNECT
LINE TO (1) HOLE
AND LEAVE OTHER
(5) PLUGGED ON EA
END PLATE.
3/8” NPT OIL
PRESSURE
CONNECTION
3/8” NPT OIL
PRESSURE
CONNECTION
3/8” NPT OIL
PRESSURE
CONNECTION
3/4” NPT COOLING
WATER
CONNECTIONS.
INLET OR OUTLET
CAN BE EITHER PORT.
3/4” NPT COOLING
WATER CONNECTIONS.
INLET OR OUTLET CAN
BE EITHER PORT.
3/4” NPT COOLING WATER
CONNECTIONS.
INLET OR OUTLET CAN BE
EITHER PORT.
3/8” NPT
OIL PRESSURE
CONNECTION
BREATHER
(1) EA END COVER
