37
ITEM
NO. PART DESCRIPTION
19
QTY
86
QTY
1 ROTOR, MECH SEAL 2 2
3 HOUSING, CI 1 1
4 END PLATE 2 2
6 DRIVE END COVER 1 1
7 FREE END COVER 1 1
8 TIMING GEAR SET 1 1
9 BEARING, DRIVE END 2 2
10 BEARING, FREE END 2 2
12 LIP SEAL 4 4
13 LIP SEAL 1 1
14 RETAINER 2 2
15 RETAINER 2 2
16 SHIM, TIMING GEAR 2 2
20 OIL SLINGER 1 1
22 DOWEL PIN 4 4
23 DRIVE SHAFT KEY 1 1
24 GEAR KEY 2 2
26 CAP SCREW 48 48
27 LOCK WASHER 6 6
30 CAP SCREW 36 36
31 MAGNETIC PLUG 2 2
32 HOSE 1 13
35 LOCK NUT 4 4
36 LOCK WASHER 4 4
37 BREATHER 2 2
41 LOCK WASHER 4 4
42 TAG - BOOSTER, CE MARK 1 1
44 HOSE 2 9
45 DRIVE SHAFT 1 1
46 SEAL ADAPTOR 1 1
50 BEARING, ROLLER 1 1
66 CAP SCREW 6 6
70 OIL SIGHT GAUGE 1 1
73 HOSE 1 30
80 BEVEL WASHER 2 2
84 HOSE 1 18
103 HOSE CLAMP 10 10
104 CAP SCREW 4 4
105 PIPE 6 6
106 PIPE — 2
107 HOSE 1 5
109 PIPE PLUG 3 3
110 CAP SCREW, HEX HD 6 6
117 LOCK WASHER 3 3
120 BUSH 1 1
121 PIPE PLUG 1 1
123 BEARING SPACER 2 2
124 OIL FILTER, SPIN ON 1 1
125 BRACKET 1 1
126 DOWEL PIN 4 4
132 PIPE 5 5
144 OIL PUMP 1 1
149 PIPE 3 7
152 ELL, ST 2 3
166 HOSE CONNECTOR 10 10
167 PIPE 3 3
PARTS LIST FOR MODEL 1200 19/86 SERIES BLOWERS
ITEM
NO. PART DESCRIPTION
19
QTY
86
QTY
168 BUSHING REDUCER 1 1
170 STREET ELBOW — 2
171 ELL, ST — 1
172 BUSHING 1 1
173 HEAT EXCHANGER, SB701-A4F 1 1
174 PIPE PLUG 26 24
176 O-RING 2 2
181 HOSE, I.D. 1 1 7
186 BRACKET 1 1
189 HEX NUT 4 4
219 RETAINING RING 4 4
228 CAP SCREW 3 3
239 SLEEVE 4 4
257 CROSS NPT 1 1
258 ELBOW, NPT 3 6
259 TEE 2 2
260 TEE, REDUCING 2 2
262 GAUGE 1 1
263 ELBOW, REDUCING 3 3
266 HOSE CLAMP 6 6
274 HOSE 1 36
280 WASHER, PTFE 20 20
281 SPACER 24 24
282 WAVE SPRING, STL 8 8
283 PIPE — 1
284 PIPE DRESSER 2 2
285 PIPE 2 2
286 PIPE TUBE 1 1
287 PIPE TOE 2 2
289 TEE 1 1
290 REDUCER BUSHING 2 2
298 REDUCER BUSHING 1 1
301 CAP SCREW 48 48
302 O-RING 2 2
304 MOUNTING FOOT 4 4
305 O-RING 4 4
306 SLEEVE 4 4
307 CAP SCREW 16 16
309 CAP SCREW 4 4
310 OIL PUMP ASSEMBLY 1 1
313 OIL PUMP ADAPTER 1 1
314 O-RING 2 2
319 LOCK NUT 1 1
320 WASHER 1 1
325 O-RING 1 1
329 PLUG, STRAIGHT THREAD 2 2
331 O-RING 4 4
336 ORIFICE FITTING 5 5
349 PIPE 1 1
351 PIPE 4 4
354 REDUCER BUSHING 5 5
NOTES:
• QUANTITIES SHOWN ARE MAXIMUM VALUES;
QUANTITIES MAY VARY BETWEEN BLOWER
PARTS KITS ARE AVAILABLE, AS FOLLOWS:
19/86 — P/N 29219
