PARTS LIST FOR MODEL 1200 66/69 SERIES BLOWERS
ITEM
NO. PART DESCRIPTION
66
QTY
69
QTY
1 ROTOR, MECH SEAL 2 2
3 HOUSING, CI 1 1
4 END PLATE 2 2
6 DRIVE END COVER 1 1
7 FREE END COVER 1 1
8 TIMING GEAR SET 1 1
9 BEARING, DRIVE END 2 2
10 BEARING, FREE END 2 2
14 RETAINER 2 2
15 RETAINER 2 2
16 SHIM, TIMING GEAR 2 2
20 OIL SLINGER 1 1
22 DOWEL PIN 4 4
23 DRIVE SHAFT KEY 1 1
24 GEAR KEY 2 2
26 CAP SCREW 48 48
27 LOCK WASHER 2 2
30 CAP SCREW 32 32
31 MAGNETIC PLUG 2 2
32 HOSE 1 1
35 LOCK NUT 4 4
36 LOCK WASHER 4 4
41 LOCK WASHER 4 4
42 TAG - BOOSTER, CE MARK 1 1
44 HOSE 2 2
45 DRIVE SHAFT 1 1
50 BEARING, ROLLER 1 1
54 MECHANICAL SEAL 4 4
66 CAP SCREW 6 6
70 OIL SIGHT GAUGE 1 1
71 ADAPTER 1 1
72 ADAPTER 1 1
73 HOSE 1 36
76 SEAL ROTOR 1 1
76 SEAL STATOR 1 1
78 RETAINING COLLAR 1 1
80 BEVEL WASHER 2 2
84 HOSE 1 1
85 PIPE PLUG 4 4
87 ADAPTER 1 1
88 O-RING 1 1
90 SET SCREW 2 2
91 SEAL ADAPTER 1 1
93 CAP SCREW 4 4
103 HOSE CLAMP 10 10
104 CAP SCREW 4 4
105 PIPE 6 6
107 HOSE 1 1
109 PIPE PLUG 4 4
110 CAP SCREW, HEX HD 2 2
117 LOCK WASHER 3 3
120 BUSH 1 1
121 PIPE PLUG 1 1
123 BEARING SPACER 2 2
124 OIL FILTER, SPIN ON 1 1
126 DOWEL PIN 4 4
132 PIPE 5 5
140 O-RING 1 1
144 OIL PUMP 1 1
149 PIPE 2 2
ITEM
NO. PART DESCRIPTION
66
QTY
69
QTY
152 STREET ELBOW 2 3
166 HOSE CONNECTOR 10 10
167 PIPE 3 3
170 STREET ELBOW 0 2
171 STREET ELBOW 0 1
172 BUSHING 1 1
173 HEAT EXCHANGER 1 1
174 PIPE PLUG 27 27
176 O-RING 2 2
178 TUBE CONNECTOR 2 2
181 HOSE, I.D. 1 1
219 RETAINING RING 4 4
220 RETAINING RING 1 1
228 CAP SCREW 3 3
239 SLEEVE 4 4
255 ROLL PIN 1 1
257 CROSS NPT 1 1
258 ELBOW, NPT 4 5
259 TEE 2 2
260 TEE, REDUCING 2 2
262 GAUGE 1 1
263 ELBOW, REDUCING 3 3
266 HOSE CLAMP 6 6
274 HOSE 1 41
280 WASHER 20 20
281 SPACER 24 24
282 WAVE SPRING, STL 8 8
283 PIPE 2 3
284 PIPE DRESSER 2 2
285 PIPE 2 2
286 PIPE TUBE 1 1
287 PIPE TOE 2 2
289 TEE 1 1
290 REDUCER BUSHING 3 3
298 REDUCER BUSHING 1 1
300 ROLL PIN 4 4
301 CAP SCREW 48 48
302 O-RING 2 2
304 MOUNTING FOOT 3 3
305 O-RING 4 4
306 SLEEVE 4 4
307 CAP SCREW 16 16
309 CAP SCREW 4 4
310 OIL PUMP ASSEMBLY 1 1
313 OIL PUMP ADAPTER 1 1
314 O-RING 2 2
325 O-RING 1 1
329 PLUG, TRAIGHT THREAD 2 2
331 O-RING 4 4
336 ORIFICE FITTING 5 5
349 PIPE 1 1
351 PIPE 4 4
354 REDUCER BUSHING 5 5
369 TUBE 1 1
408 FOOT ASSEMBLY, MTG VERT 1 1
NOTES:
• QUANTITIES SHOWN ARE MAXIMUM VALUES;
QUANTITIES MAY VARY BETWEEN BLOWER
PARTS KITS ARE AVAILABLE, AS FOLLOWS:
66/69 — P/N 29217
