15
Dimensions shown are subject to change. Dimensions are shown in inches and millimeters.
T650 AND T950H DIMENSIONAL DRAWING
NOTES
15.99
406
T650:
Ø 1.63” Shaft
with 3/8” Keyway
T950H:
Ø 40mm Shaft
with 12mm Keyway
2.58
66
15.78
401
13.20
335
10.68
271
2.52
64
18.10
460
20.47
520
22.31
567
Ø 4.00 TTMA
Discharge Flange
*
* Purchased Separately
Filter Indicator
Connection
1/8” NPT
(Both Sides)
Ø 5.00 Inlet *
Oil Fill Plugs
(Both Sides)
Sight Glass
(Both Sides)
