Tuthill T855 - Specifications

Operator’s Manual 2023 Rev G p/n 2023
7
04
Installation
WARNING
!
The blower and accessories will
become hot enough to cause serious
skin burns on contact.
Rotating machinery is dangerous.
Always wear ear protection when
near an operating blower.
SPECIFICATIONS
MODEL AIR FLOW RANGE
MAXIMUM
PRESSURE
MAXIMUM
VACUUM
RPM RANGE
T855
250 – 1,000 CFM
(424 – 1,699 m³/h)
20 psig
(1.37 bar g)
17 inch‑Hg
(575 Mbar)
1,000 – 3,000
(Pressure)
750 – 3,000
(Vacuum)
T1055
450 – 1,300 CFM
(765 – 2,209 m³/h)
18 psig
(1.24 bar g)
17 inch‑Hg
(575 Mbar)
1,200 – 3,000
(Pressure & Vacuum)
T855RS
121– 1,010 CFM
(206 – 1,716 m³/h)
20 psig
(1.37 bar g)
18 inch‑Hg
(609 Mbar)
600 – 3,000
(Pressure & Vacuum)
OTE: N Reduce the maximum operating pressure by 1 psi (0.068 bar) for each 2,000 feet (610 m) of
elevation above sea level.
Example: At an elevation of 4,000 feet (1,219 m), the maximum working pressure of the blower will
decrease by 2 psi (0.137 bar).
Table 4-1 – Specifications
