Tuthill T855 - T855 RS Performance Specifications

Operator’s Manual 2023 Rev G p/n 2023
5
03
T855RS
T855 with RS Advanced Technology™ Pressure Operating Parameters
RPM
7 PSIG 12 PSIG 16 PSIG 18 PSIG 20 PSIG
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
600 127 6.5
750 194 5.8 147 13.7
1000 281 7.8 236 18.3 212 24.4 201 27.4
1250 333 8.9 323 22.9 301 30.5 289 34.2 278 38.0
1500 384 10.1 410 27.5 388 36.5 377 41.1 367 45.6
1750 488 12.4 497 32.1 475 42.6 465 47.9 454 53.2
2000 627 15.5 584 36.6 562 48.7 552 54.8 542 60.8
2500 800 19.4 757 45.8 736 60.9 726 68.4 716 76.0
3000 973 23.3 930 55.0 909 73.1 899 82.1 889 91.2
Table 3-1 – T855RS Pressure Operating Parameters
T855 with RS Advanced Technology™ Vacuum Operating Parameters
RPM
2" Hg 10" Hg 12" Hg 17" Hg 18" Hg
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
600 179 1.0 132.4 4.6 121 5.5
750 231 1.3 184.3 5.7 173 6.8 138 9.6
1000 318 1.7 270.8 7.6 259 9.1 224 12.8
1250 404 2.1 357.3 9.5 346 11.4 311 16.0
1500 491 2.5 443.8 11.4 432 13.6 397 19.2 389 20.3
1750 577 2.9 530.3 13.3 519 15.9 484 22.4 475 23.7
2000 664 3.4 616.8 15.2 605 18.2 570 25.6 562 27.1
2500 837 4.2 789.8 19.0 778 22.7 743 32.0 735 33.9
3000 1010 5.1 962.8 22.8 951 27.3 916 38.4 908 40.6
Table 3-2 – T855RS Vacuum Operating Parameters
SPECIFICATIONS
Blue cell coloring indicates new T855RS performance
capability parameters vs T855 standard.
Figure 3-2 – T855RS with Optional Mounting Plate Adaptor
Use caution when working around rotors as
damage to the coating could result in loss
of performance. Ensure inlet only receives
lteredcleanair.
