Tuthill T855 - Component Parts List

Operator’s Manual 2023 Rev G p/n 2023
29
08
Assembly Drawing and Parts List
PARTS LIST
ITEM
NO.
PART DESCRIPTION QTY
1 ROTOR DRIVE MACH D.I. T850 1
2 ROTOR, DRIVEN, MACHINE, D.I., T850 1
3 HOUSING, MACHINE, C.I., T850 1
4 ENDPLATE MACHINE,C.I., T855/1055 2
6
COVER,MACHINE DE, ALUMINUM,
T855/1055
1
7
COVER,MACHINE GE,ALUMINUM,
T855/1055
1
8 GEAR ASSEMBLY 1
9 BEARING, BALL, 2 ROW 2
10 BEARING, ROLL CYLINDER, T850 2
11 SHIM, BEARING, 2.000 ID X 0.025 THICK 2
12 SEAL ASSEMBLY PISTON RING/LIP, VITON 4
13 OIL SLINGER ASSEMBLY, DRIVE 1
15 PLUG, MAGNETIC, 1/2 SQUARE HEAD 2
17 SEAL, TRIPLE LIP, VITON, 1.875 I.D. 2
19 PLUG, MELT, 360 DEGREES 2
20 PLUG, TRUCK BLOWER BLANK 2
21 OIL SIGHT GAGE, 1/2 NPT GLASS, QX/TRK 2
23 KEY, GEAR TIMING 2
24 WASHER, ROTOR SHAFT 3
25 SCREW, CAP, HEX HEAD, 1/2 X 1‑1/4 3
28 SCREW, CAP, SOCKET HEAD, 3/8 20
29
SCREW,FLANGE HEAD,3/8‑16X1",THREAD
LOCK
16
30 PIN, DOWEL, 1/2 X 1 6
36 PLUG, PIPE, 1/2 HEX, STEEL 10
40 BREATHER BUSHING ASSY IP69K 2
42 NAMEPLATE 1
43 DOWEL, 1/2 X 1 5/8 2
44 KEY, 3/8 SQUARE X 1 5/8 1
45 SCREW, LOCK, T850 2
47 SCREW, SET, 6MM X 12MM 2
48 SCREW, CAP, HEX HEAD, 5/16 8
49 BEARING RETAINER, T855/1055 2
14A SLINGER,DRIVEN,T855 T1055 1
14B
SPACER, OIL, SLINGER, DRIVEN,
T855,T1055
1
ITEM
NO.
PART DESCRIPTION QTY
31C SHIM, BEARING, 2.000 ID X 0.003 THICK 2
31D SHIM, BEARING, 2.000 ID X 0.004 THICK 4
31E SHIM, BEARING, 2.000 ID X 0.005 THICK 2
61580 Service Kit for T855 / T1055
ITEM /
PART #
PART DESCRIPTION QTY
9 BEARING, BALL, 2 ROW 2
10 BEARING, ROLL CYLINDER, T850 2
11 SHIM, BEARING, 2.000 ID X 0.025 THICK 2
12
SEAL ASSEMBLY PISTON RING/LIP,
VITON
4
17 SEAL, TRIPLE LIP, VITON, 1.875 I.D. 2
40 BREATHER BUSHING ASSY IP69K 2
31C SHIM, BEARING, 2.000 ID X 0.003 THICK 2
31D SHIM, BEARING, 2.000 ID X 0.004 THICK 4
31E SHIM, BEARING, 2.000 ID X 0.005 THICK 2
23 KEY, GEAR TIMING 2
60044 SHIM, ADJUSTABLE 1
61518 GASKET, PORT, T850/T1050, NA1100 2
61484 Service Kit for T850 / T1050
PART # PART DESCRIPTION QTY
ALL PARTS LISTED ABOVE FOR 61580 SERVICE KIT ARE
INCLUDED, AS WELL AS THE FOLLOWING:
61287 GASKET, T850 2
61590 Mounting Adaptor Plate Kit for T855 / T855RS
ITEM /PART # PART DESCRIPTION QTY
RS61258‑121 DRIVE ROTOR 1
RS61259‑121 DRIVEN ROTOR 1
61587 ADAPTOR PLATE 1
61589 BOLT KIT 1
61518 GASKET 1
