.XXXX =
MACHINE TOLERANCES
BREAK ALL SHARP EDGES, CORNERS,
DEBURR AND CLEAN
2 DEGANGULAR = 1/2 DEG CHAMFERS =
[METRIC]
X. = .5mm
.X = .25mm
.XX = .15mm
.XXX = .015mm
U.S. CUSTOMARY
.0005in
.XX = .01in
.XXX = .005in
PACK WITH
A-A
SCALE 1 : 1
16564-1 GREASE
SEAL SHALL NOT EXTEND
PAST EDGE OF BOAR
CHAMFER TO SEAL
.06 CLEARANCE SHAFT
.08 MIN
ASSEMBLY
STANDARD
PISTON/SLINGER SEAL
ROTOR SHAFT SEAL DETAIL (ITEM 5)
SH
1 OF 1
DWG NO
1:2
T855
T855
REV
368.8 LB
RT/SJ
07/21/2017
07/21/2017
TAAL
ANY OTHER PURPOSE WHATSOEVER.
SUPPLIER IT SHALL BE USED SOLELY IN THE PERFORMANCE OF WORK CONTRACTED FOR BY THE COMPANY. THE INFORMATION SHALL NOT BE USED OR DISCLOSED BY THE RECIPIENT FOR
SCALE WEIGHT
REV
DWG NO.
SHEET
SIZE
TITLE
APPROVALS
DATE
CHECKED
DRAWN
APPLICATION
NEXT ASSY USED ON
THIRD ANGLE PROJECTION
D
C
1 OF 1
C
T855 BLOWER ASSEMBLY
NOTICE OF CONFIDENTIAL INFORMATION
INFORMATION CONTAINED HEREIN IS CONFIDENTIAL AND IS THE PROPERTY OF THE TUTHILL CORPORATION. WHERE FURNISHED WITH A PROPOSAL THE RECIPIENT SHALL USE IT SOLELY TO
EVALUATE THE PROPOSAL. WHERE FURNISHED TO A CUSTOMER IT SHALL BE USED SOLELY FOR THE PURPOSES OF INSPECTION, INSTALLATION OR MAINTENANCE. WHERE FURNISHED TO A
VACUUM & BLOWER
SYSTEMS
REVISIONS
REV ECN DESCRIPTION DATE DR CK
B 8014
1) BEARING REATINER QTY WAS 3 2) WAS SOCKET
HEAD AND QTY 9 3) WAS SOCKET HEAD CAP SCREW
4) DELETED LIP SEAL COLUMN
9/15/2017 SJ CG
C 8061 REPLACED WITH UPDATED ENDPLATE 10/13/2017 SJ CG
D 8607 TRANSPORT BLOWER ENHANCMENT PROJEC T 11/01/2019 BD
ITEM
NO.
PART NUMBER DESCRIPTION
Default
/QTY.
0000 2023 MANUAL 2023 - T855 T1055 1
0000 9674 SEALANT, LOCTITE #5699, Grey RTV 1
0000 60044 SHIM, ADJUSTABLE 1
0000 61581 '--BOLT KIT, T850/T1050/T855/T1055 1
0000 92314 ADHESIVE THREAD LOCK 1
0000 93365 CRATE, T850/T1050/855/1055 1
0000 16444-MD2-Q OIL, MD-PLUS, QUART 4
0000 16564-1 GREASE, PNEULUBE, LITHIUM, 1 TUBE, 14 OZ 1
0000 18906-2 PAINT,BLACK,ACRYLIC ENAMEL 0.010
0000 S-573 T850/TI850/T1050 TEST PROCEDURE 1
0001 61258-121 ROTOR DRIVE MACH D.I. T850 1
0002 61259-121 ROTOR, DRIVEN, MACHINE, D.I., T850 1
0003 61238-101 HOUSING, MACHINE, C.I., T850 1
0004 61575-101 ENDPLATE MACHINE,C.I., T855/1055 2
0006 61573-128 COVER,MACHINE DE, ALUMINUM, T855/1055 1
0007 61574-128 COVER,MACHINE GE,ALUMINUM, T855/1055 1
0008 61282 GEAR ASSLY NOT FOR SALE (see 61585) 1
0009 30238-5310 BEARING, BALL, 2 ROW 2
0010 30410-2310 BEARING, ROLL CYLINDER, T850 2
0011 17024-25 '--SHIM, BEARING, 2.000 ID X 0.025 THICK 2
0012 18131-6D SEAL ASSEMBLY PISTON RING/LIP, VITON 4
0013 16928-2 OIL SLINGER ASSEMBLY, DRIVE 1
0015 90242 '--PLUG, MAGNETIC, 1/2 SQUARE HEAD 2
0017 16924 SEAL, TRIPLE LIP, VITON, 1.875 I.D. 2
0019 92278 PLUG, MELT, 360 DEGREES 2
0020 93361 PLUG, TRUCK BLOWER BLANK 2
0021 93334-050 OIL SIGHT GAGE, 1/2 NPT GLASS, QX/TRK 2
0023 61370 '--KEY, GEAR TIMING 2
0024 60026 WASHER, ROTOR SHAFT 3
0025 90170-125 '--SCREW, CAP, HEX HEAD, 1/2 X 1-1/4 3
0028 90174-100 '--SCREW, CAP, SOCKET HEAD, 3/8 20
0029 90174-050 SCREW,FLANGE HEAD,3/8-16X1",THREAD LOCK 16
0030 91458-100 '--PIN, DOWEL, 1/2 X 1 6
0036 91572 '--PLUG, PIPE, 1/2 HEX, STEEL 10
0040 61047-A50 BREATHER BUSHING ASSY IP69K
0042 18491-1 NAMEPLATE 1
0043 61224-162 '--DOWEL, 1/2 X 1 5/8 2
0044 8268 '--KEY, 3/8 SQUARE X 1 5/8 1
0045 61225 SCREW, LOCK, T850 2
0047 80043-12 '--SCREW, SET, 6MM X 12MM 2
0048 90354-075 '--SCREW, CAP, HEX HEAD, 5/16 8
0049 61576 BEARING RETAINER, T855/1055 2
014A 16927-4 SLINGER,DRIVEN,T855 T1055 1
014B 16926-4 Spacer,oil,slinger,driven,T855,T1055 1
031C 17024-3 '--SHIM, BEARING, 2.000 ID X 0.003 THICK 2
031D 17024-4 '--SHIM, BEARING, 2.000 ID X 0.004 THICK 4
031E 17024-5 '--SHIM, BEARING, 2.000 ID X 0.005 THICK 2
D
D
D
D
D
D
D
D
D
SCALE 1:4
SEE ROTOR SHAFT
A-A
9
4
14B
10 11
12
12
13
48
2
7
3
25
6
24
(ITEM 5) BELOW
SEAL DETAIL
14A
40
1
8
17
23
15
4
12
30 31
DRIVE SHAFT SEAL DETAIL
29
28
19
21
20
36
40
