FHD Hight Bright Field Monitor
07 OTHER FUNCTIONS
[9] HDMI To SDI CONVERSION-OUT / SDI To HDMI CONVERSION-OUT
• Video source from ‘HDMI input’ terminal can be
output through ‘SDI throughout’ terminal.
Output
Format
Input
Format
1080/50p 1080/60p
480/59.94i
●
576/50i
●
480/60p
●
576/50p
●
720/50p
Converted out in the same format
as the input format
720/59.94p
720/60p
1080/50i
1080/59.94i
1080/60i
1080/24p
1080/25p
1080/30p
1080/50p
1080/59.94p
1080/60p
• 3G/HD/SD SDI signals from ‘SDI input’ terminal
can be output through ‘HDMI out’ terminal.
Output
Format
Input
Format
1080/50p 1080/60p
480/59.94i
●
576/50i
●
720/50p
●
720/59.94p
●
720/60p
●
1080/50i
●
1080/59.94i
●
1080/60i
●
1080/24p
●
1080/25p
●
1080/30p
●
1080/24psF
●
1080/50p
●
1080/59.94p
●
1080/60p
●
HDMI TO SDI CONVERSION-OUT SDI TO HDMI CONVERSION-OUT
※ Note : DSLR camera manufacturers usually specify the resolution and frame rate for the recording.
The signal format that is output through HDMI terminal of cameras may dier from makers to makers.
The signal format for HDMI output and playback function of Canon DSLRs is 59.94i. And even though
60i or 60p is specied in the specication of the cameras, the actual recording or HDMI output format
would be 59.94i or 59.94p.
