TVS King GS+ - Rear View and Engine Compartment

KNOW YOUR VEHICLE
1
2
3
4
5
6
7
VEHICLE REAR
1. Rear combination Lamp RH
2. Rear number plate lamp
3. Rear number plate
4. Mud Flap
5. Exhaust assembly
6. Rear Tail Door
1. Air filter assembly
2. Cover TCI unit
4. Secondary Air Injection (SAI)
5. Spark plug
7. EVAP Unit
6. Petrol tank
7. Rear combination Lamp LH
3. Carburetor
ENGINE COMPARTMENT
VEHICLE REAR & ENGINE ROOM
3
1
4
2
10
5
6
7
