18
On pushing the turn signal switch in left or right ‘ ’the ïð
respective indicator lamps will glow in both front and rear. It
gives an indication in which direction you are turning.
Always use the appropriate turn signal lamps when you take
a turn.
Switch off turn signal lamp after negotiating turn.
c) Turn signal lamp switch (Left & Right)
To turn off turn signal lamp bring the switch to central
position.
WARNING
Switch assembly center
3. Hazard switch
Press this switch ‘ ’ to operate warning lamps in case of
vehicle breakdown on road for repair or emergency. This
switch can be operated even when ignition is in OFF
position.
It is located on the wind shield frame above dash board.
5. Mobile charger
Your TVS King comes with mobile charger ( A ) on
dashboard LH side as shown in the above fig.
4. Wiper motor.
Wiper motor
A
FEATURES IN YOUR VEHICLE
3
4
