TVS King GS+ - Tyre and Wheel Changing Procedure

31
- Lift up the vehicle until the wheel clears the ground.
NOTE
- Apply parking brake
Removal
While mounting the spare wheel on the frame driver seat
always make sure that air filler valve is facing down wards.
Tyre and wheel changing procedure.
- Loosen the wheel retaining nuts diagonally. (4 nos.)
- Place the jack as shown in the fig. (For removing front
wheel B. rear wheel A.)
- Remove the retaining nuts and take out the wheel.
Spare wheel removal
Assembly
Tool name Tool size
Rear 30 psi 34 psi
- Lower the vehicle slowly to the ground then tighten the nuts
fully to the recommended torque.
- While assembling the spare wheel tighten the wheel nuts
diagonally.
Ring spanner, Socket spanner 17mm
Tyre pressure
Un-laden Laden
Front 30 psi 30 psi
Jack position front - BJack position rear - A
A
B
SELF MAINTENANCE PROCEDURE
