7

6. Logo grill

9. Rear view mirror

1. Wiper blade

5. Front brake fluid hose

2. Turn signal lamp

4. Position lamp

3. Head lamp

7. Number plate front

8. Wind shield glass

KNOW YOUR VEHICLE

FRONT VIEW

FRONT VIEW

1

2

3

4

5

6

7

8

9

8

7

1

3

4

5

6

2

DRIVER CABIN - RH

DRIVER CABIN - RH

1.Handle bar

6. Brake Pedal

3. Dash board

4. Hand brake control lever

5. Tandam master cylinder

2. Wiper Motor

8. Driver seat

7. Spare wheel

Table of Contents

Foreword3
Notice4
Accessorice Details5
Safety Information6
Table of Contents7
Know Your Vehicle8
Vehicle Identification Number8
Driver Cabin9
Front View9
Control Panel10
Switch - LH/RH11
Vehicle - LH11
Engine Compartment12
Know Your Vehicle12
- Vehicle Rear and Engine Room12
- Technical Specifications13
- Features in Your Vehicle15
- Control Key Operations16
- Ignition Switch16
- Steering Lock16
- Fuel Lid Lock17
- Rear Tail Door17
- Safety Features18
- Switch Assembly LH18
- Utility Box and Glove Box18
- Head Lamp High/Low Beam Switch19
- Horn Switch19
- Switch Assembly RH19
- Wiper Motor Switch19
- Hazard Switch20
- Mobile Charger20
- Turn Signal Lamp Switch20
- Wiper Motor20
- Control Features21
- Parking Brake Lever21
- Speedometer and Odometer21
- Tell Tale Lamp22
- Clutch Lever23
- Tube Complete Gear Shift23
- Tube Complete Throttle23
- Choke Lever24
- First Aid Kit24
- Hand Starter Lever24
- Tool Kit24
Safe Riding Tips25
- Running-In Information26
- Useful Information26
Operating Your Vehicle27
- Setting the Vehicle in Motion27
- Starting the Vehicle27
- Fuel Saving Tips28
- Reverse Gear Operation28
- Stopping and Parking28
- Differential Oil Level Checking and Topping up29
- Engine Oil Level Checking and Topping up29
- Self Maintenance Procedure29
- Engine Oil Replacement30
- Differential Oil Replacement31
- Low Engine Oil Pressure Indicator31
- Changing Tyres and Wheels32
- Cleaning the Spark Plug32
- Spare Wheel Removal33
- Tyre and Wheel Changing Procedure33
- Brake Fluid Level Checking and Topping up34
- Brakes34
Self-Maintenance Procedures34
- Tyre Rotation34
- Electrical35
- Head Lamp Bulb Removal35
- Rubber Bellows for Propeller Shaft35
- Tail/Brake/ Rear Turn Signal Lamp Bulb35
- Battery Fuse Replacement/Removal36
- Bulb Removal36
- Front Turn Signal Bulb Replacement36
- Throttle Cable Adjustment36
- Clutch Cable Adjustment37
- Throttle Cable Adjustments37
- Clutch Cable Assembly at Engine End38
- Clutch Cable Assembly at Pulley End38
- Clutch Cable Inner Replacement38
- Gear Cable Assembly at Engine End39
- Gear Cable Inner Replacement39
- Air Filter Cleaning40
- Hydraulic Brake System41
Service Record Sheet42
Basic Trouble Shooting43
Periodic Maintenance Schedule46
Recommended Lubricants48
