SELF MAINTENANCE PROCEDURE
29
Differential Oil Replacement
- Park the vehicle on level ground
- Place a pan under the drain plug and remove the oil
drain plug with plain washer. Drain the oil completely.
- Refit drain plug along with plain washer and tighten it.
- Tighten filler bolt. Check oil level
- Replace differential oil at every 5000 km
- Run the Engine for a few minutes to warm up the oil
- Loosen and take out the filler bolt and fill correct
quantity of recommended oil
- Allow some time for the oil to settle down.
CAUTION
- Always use recommended transmission and differential oil.
- Two different grade and brand of oil should not be mixed.
Low Engine Oil Pressure Indicator
- It is located on cluster assembly tell tale lamp as shown
in the figure.
- This indicator must glow in Ignition switch ON and
before starting the engine.
Ring spanner, Tubular spanner 17mm
Tool name Tool size
Differential Oil Replacement
Engine Oil Pressure Indicator
Engine oil pressure indicator
