TVS King GS+ - Engine Oil Replacement

28
- To top up oil loosen filler bolt using 17mm spanner.
- Fill recommended oil and tighten filler bolt with washer.
- Tighten the level plug with washer with out fail.
- Park the vehicle on level ground
- Allow some time for the oil to settle down.
- Run the Engine for a few minutes to warm up the oil
Engine Oil Replacement
- Refit drain plug along with plain washer and tighten it.
- Insert and tighten the dip stick completely.
- Remove the dip stick and pour the correct quantity of
recommended oil.
- Place a oil pan under the drain plug and un-screw hex.
flange nuts (2nos.) and take out the cover oil strainer(B)
- Check the oil level.
- Replace engine oil at every 5000 kms.
Tool name Tool size
Ring spanner, Socket spanner 10mm,17mm
Differential oil level checking and topping up
Tool name Tool size
Ring spanner 10 mm
Engine Oil Replacement
SELF MAINTENANCE PROCEDURE
B
