POOR PICK – UP
STEP REASON POSSIBLE CAUSE COUNTER MEASURE
1 No free movement of wheel Brake binding Adjust brakes
Low tyre pressure Inflate to specification (refer page no.31)
High friction in between flange & slider block Lubricate with grease (refer page no.33)
4 Tyre Low tyre pressure Inflate to specification (refer page no.31)
ELECTRICAL SYSTEM
3 Improper power transfer to wheel Slider block and flange worn out Replace (Refer note) - Page No.65
5 Faulty engine Faulty carburettor, poor compression Repair engine (refer note) - Page No.65
4 Improper ignition Refer step no. 3 of (Engine does not start) - Page No.63
EXCESSIVE FUEL CONSUMPTION
3 Spark plug Dirty / excess spark plug Clean and adjust gap
STEP REASON POSSIBLE CAUSE COUNTER MEASURE
Wiring cut/disconnected Replace/connect (refer note) - Page No.65
Clutch plates worn out Replace (Refer note) - Page No.65
STEP REASON POSSIBLE CAUSE COUNTER MEASURE
1 Horn not working Fuse blown Replace (refer page no.34)
Battery discharged Recharge (refer note) - Page No.65
2 Air cleaner choked Filter elements clogged with dust Clean the air cleaner foam element (Refer page no.38)
2 Clutch slippage Incorrect free play Adjust free play
Horn switch contact points worn out Correct / Replace (refer note) - Page No.65
Defective horn Replace (refer note) - Page No.65
1 Fuel leakage Leakage from fuel tank, hose and joints Correct leakage (Refer note) - Page No.65
42
