LOCATION OF PARTS - HANDLE BAR
1. Fuel tank cap
2. Horn switch
3. Turn signal lamp switch
4. Clutch lever
5. Rear view mirror L
6. Pass by switch
7. High / low beam switch
8. Instrument cluster
9. Ignition cum steering lock
10. Master cylinder (front)
11. Rear view mirror R
12. Engine cut off switch
13. Front brake lever
14. Throttle grip
15. Electric starter switch
KNOW YOUR TVS STRYKER 3V
07
1
2
3
4
7
8
6
9
11
12
13
10
14
15
