TVS Stryker 3V 2021 - Instrument Cluster: Illumination & Units

Illumination Control :
Customer can control the brightness of their
speedometer.
Two modes of control available:
Day condition (6.00 am to 6.00pm): 100 % (Not
changeable)
Night condition (6.00pm to 6.00am): 100 % (Default) -
three step control possible
Illumination Setting Mode:
Ensure the display is in LAP mode.
MPH and KMPH setting
Default setting is in KMPH.
KNOW YOUR TVS STRYKER 3V
M o d e /
Set Switch
M o d e /
Set Switch
Set
Mode
Set
Mode
Long
press
> 10 sec
Long
press
Short
press
Enter illumination mode.Once
e n t e r e d ‘ I L L U ’ w i l l b e
displayed in Trip zone and
current illumination level will
be shown in Odo display zone
‘- - - -’
Ignition key in OFF position,
press and hold the mode
button and then turn ON
ignition key and keep holding
mode button for more than
10sec to change unit from Km
to miles and vice-versa.
Enter illumination value will be
u p d a t e d a n d e x i t f r o m
illumination mode and move
to Odo mode
Reduce the illumination
percentage
P r e s s
Duration
P r e s s
Duration
Action
Action
