ELECTRICAL
Body earthing : Negative terminal
Head lamp : 12V, 10Wx3 LED
Tail / brake lamp : 12V, 0.3W/2.5W x 14 LED
Turn signal lamp : 12V, 10W x 4
Instrument panel : LCD / LED indicators
Horn : 12V, DC x 1
Fuse : 12V, 15A x 1(main), 12V, 10Ax1
( D C l o a d ) & 1 2 V , 4 0 A x 1
(starting)
CAPACITIES
Fuel tank capacity : 10 liters (RON 92 and above &
unleaded)**
Reserve : Auto fuel cock
Engine cum transmission : TVS TRU4 FULLY
oil grade SYNTHETIC ( SAE 10W30 API
SL JASO MA2) or
TVS TRU4 PREMIUM (SAE
10W30 API SL JASO MA2)
Engine cum transmission : 1000 ml (During regular service)
oil capacity 1100 ml (incase of disassembly)
Front fork oil grade : IOC / Castrol teleshockab oil
Front fork oil capacity : 155 ± 2 ml per leg
Brake fluid : TVS Girling DOT 3 / DOT 4
…
The fuel tank is not a measuring instrument and the
capacity of fuel tank may slightly vary from the indicated
capacity.
TECHNICAL SPECIFICATIONS
Using the bulb other than the specified rating can result in
overloading of the electrical system or premature failure
of the bulb.
Specifications are subjected to change without notice.
CAUTION
NOTE
62
