BRAKES
Front brake
You can observe a master cylinder (1) on the right side
of the handle bar, a caliper assembly (2) fitted to the
fork leg R, a disc (3) to the front wheel and a high
pressure hose (4) connecting the master cylinder and
the caliper assembly.
1. Check the master cylinder brake fluid level
through the view piece glass (A).
2. Brake fluid level always should be above the 'MIN'
mark (B) provided on the master cylinder view
piece glass when the master cylinder is parallel to
the ground.
3. If the brake fluid level is below the mark or while
applying brake if you feel the brake is more spongy
or ineffective due to air entry, contact TVS Motor
Company Authorised Main Dealer or Authorised
Dealer for topping-up the brake fluid, air bleeding
and other brake related inspections.
Brakes are items of personal safety and should always
be maintained in proper condition.
Warning
1
3
2
4
MAINTENANCE
46
