TVS Stryker 3V 2021 - Drive Chain Cleaning and Lubrication

MAINTENANCE
Check, clean, lubricate and adjust the drive chain in
the following manner:
1. Place the vehicle on centre stand with the
transmission in neutral.
2. Remove the dust seal chain cover.
3. Inspect the drive chain slackness (vertical
movement) using the finger as shown in the
figure.
4. The slackness of the drive chain should not
exceed the limit (maximum 20 ~ 30 mm). Excess
slackness consumes more fuel.
5. If the slackness is found more, contact TVS Motor
Company Authorised Main Dealer / Authorised
Dealer for adjustment.
6. If the slackness found is within the limit, clean the
chain with dry cloth and lubricate using TRU
SPRAY / TRU4 oil.
7. Refit the dust seal chain cover.
52
