twintex LCR Series User Manual

- 36 -
4.2 String Format
When writing commands, the “Command Code” in below table must be expressed in the way of ASCII code. For
example, command string {A0} in ASCII code is 7B41307D. Only one of the following command can in contained
in one string. Each command must be started with { and ended with }.
No.
Command Code
Numbers of
Characters
Control Function
1
A0
2
Measure parameters, series and parallel: L-Q
2
P
A1
2
Measure parameters, series and parallel: C-D
3
A2
2
Measure parameters, series and parallel: R-Q
4
A3
2
Measure parameters, series and parallel: Z-r
5
B0
2
Measure frequency: 10kHz
6
B1
2
Measure frequency: 1kHz
7
B2
2
Measure frequency: 120Hz
8
B3
2
Measure frequency: 100Hz
9
B4
2
Measure frequency: 60Hz
10
B5
2
Measure frequency: 50Hz
11
C0
2
Measure level: 1V
12
C1
2
Measure level: 0.3V
13
C2
2
Measure level: 0.1V
14
D0
2
Display mode: Δ%
15
D1
2
Display mode: Direct reading
16
D2
2
Display mode: ABS deviation
17
E0
2
Hold in the current range.
18
E1
2
Auto ranging.
19
E2
2
Hold in 0 range 100kΩ.
20
E3
2
Hold in 1 range 10kΩ.
21
E4
2
Hold in 2 range 1kΩ.
22
E5
2
Hold in 3 range 100Ω.
23
E6
2
Hold in 4 range 31.6Ω.
24
E7
2
Hold in 5 range 10Ω.
25
F0
2
Measurement speed: FAST.
26
F1
2
Measurement speed: SLOW.
27
F2
2
Measurement speed: MEDIUM.
28
G0
2
Short circuit clear.
29
G1
2
Open circuit clear.
30
G2
2
Fixed point frequency short circuit clear.
31
G3
2
Fixed point frequency open circuit clear.
32
H0
2
Beeper: MASTER.
33
H1
2
Beeper: EARPHONE.
34
I0
2
Trigger: (OFF) Continuous.
35
I1
2
Trigger: (ON) Single.
36
J0
2
Equivalent format: (SER) series.
37
J1
2
Equivalent format: (PER) parallel.
38
K0
2
RS232 interface: (OFF) only receive data (single direction).
39
K1
2
RS232 interface: (ON) Allow to send data (Bi-direction).
40
L0
2
Comparator mode: P1
41
L1
2
Comparator mode: P3
42
L2
2
Comparator OFF
43
L3
2
Comparator ON
44
M0
2
Source resistance: 30Ω
45
M1
2
Source resistance: 100Ω
