2-3. <MEAS SETUP>

Press [SETUP] key, <MEAS SETUP> page will be displayed on screen as shown below:

< MEAS SETUP >

MEAS

SETUP

ResSource

AVERAGE

RangeDwe I I

TrigSource

TrigDelay

TrigEdge

Handler

PulseWidth

: 30Ω

: 1

: 0 ms

: INT

: 0 ms

: RISING

: CLEAR

: 1 ms

Use softkeys to select

ResSource

Set internal resistance source at 30Ω or 100Ω

AVERAGE

Set average number of times between numbers 1 to 255. Input numbers by numeric keys or

soft key “+” and “-”.

RangeDwe I I

Set range delay time between 0ms to 6000ms. Input numbers by numeric keys or soft key “+”

and “-”.

TrigSource

Set trigger source as INT or EXT.

TrigDelay

Set trigger display time between 0ms to 6000ms. Input numbers by numeric keys or soft key

“+” and “-”.

TrigEdge

Set trigger edge as RISING or FALLING.

Handler

Set comparator to CLEAR, HOLD, PULSE.

PulseWidth

Set pulse width between 1ms to 9999ms.
