twintex LCR Series User Manual

- 9 -
Monitored Voltage and Current
Vm and Im are monitored voltage and current of the DUT respectively. When Vm or Im is selected, it can be set
ON or OFF.
< MEAS DISP >
ON
FUNC : Cp-D
RANGE : AUTO
FREQ : 1 kHz
SPEED : SLOW
OFF
LEVEL : 1.00V
COMP : OFF
／
Cp
: -
0.0015p F
D
:
0.3697
Vm:OFF
Im:OFF
Use softkeys to select
2-2. <BIN DISPLAY> (available for 200kHz model only)
Press [BIN DISP] key in the pay of <MEAS DISP>, the <BIN DISPLAY> page will be displayed on screen as
shown below:
< BIN DISP >
MEAS
DISP
COMP : OFF AUX : OFF COUNT : OFF
NOMINAL: 0.0000pF MODE : ABS
BIN
DISP
BIN
LOW [ ]
HIGH [ ]
COUNT
1
2
3
2nd
AUX : OFF
OUT :
＼
Cp : - 0.0009p F
D : 0.0033
BIN:
Quick
Clear
Use softkeys to select
COMP: Set comparator ON or OFF
AUX: Set auxiliary ON or OFF
COUNT: Set counting ON or OFF
NOMINAL: Input nominal value via numeric keys or softkeys. It is reference value of main parameter range.
Deviation is for main parameters only. There are 3 operations to Deviation: OFF, ABS or %.
➔ ABS (Absolute Deviation): The absolute deviation is the currently measured value minus preset nominal
value. Its calculation formula is: ⊿ABS = X – Y.
X is the currently measured value. Y is preset nominal value.
➔ % (percentage deviation): The percentage deviation is the percentage of the difference between the
currently measured value and the preset nominal value. Its calculation formula is: ⊿% = （X – Y）/ Y×
100[%]
X is the currently measured value. Y is preset nominal value.
