twintex LCR Series User Manual

- 13 -
2-6. <ABOUT SYSTEM>
Press [ABOUT SYSTEM] softkey, the <ABOUT> page will be displayed on screen as shown below:
< ABOUT >
Reset
Factory
Model number:
Serial number
Firmware version
Hardware version
License
:
: xx-xxx-xxxxx
: x.x.x
: x.x.x
: Registered
DEL
Update
EXIT
Use softkeys to select
Reset
Press the softkey to restart the LCR meter.
Factory
Press the softkey to return to factory setup. Password is required.
Update
Press the softkey to update firmware through USB flash disk.
EXIT
Press the softkey to exit and return to <SYSTEM SETUP> page.
2-7. Data Storage
The measurement data can be stored to USB flash stick. In <MEAS> page, press [TOOL] key to enter into data
storage menu.
< MEAS DISP >
PrtSc
FUNC : Cp-D
RANGE : AUTO
FREQ : 1 kHz
SPEED : SLOW
SAVE
DATA
LEVEL : 1.00V
COMP : OFF
／
Cp
: -
0.0015p F
DEL
D
:
0.3697
SINGLE
SHORT
Vm:OFF
Im:OFF
SINGLE
OPEN
Use softkeys to select
There are three formats for data storage: <A>，<B> [，<COMP>]
A and B are measurement results for main parameter and secondary parameter respectively. The measurement
results are stored in the way of scientific notation.
<COMP> is comparator results. 10kHz and 30kHz models do not have handler function.
COMP
Description
COMP
Description
0
Fail
3
BIN 3pass
1
BIN 1 pass
4
AUX fail
2
BIN 2 pass
5
No comparator
