3.4.2.2 DMI Configuration
Aptio Setup Utility --- Copyright © 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Enable or disable DMI Vc1
DMI Configuration
DMI
DMI Vc1 Control
DMI Vcp Control
DMI Vcm Control
DMI Link ASPM Control
DMI Extended Synch Control
DMI Gen 2
x4 Gen2
[Enabled]
[Enabled]
[Enabled]
[L0sL1]
[Disabled]
[Auto]
→←: Select screen
↑↓: Select item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
DMI Vc1 Control
Enable or disable DMI Vc1.
Enabled / Disabled
DMI Vcp Control
Enable or disable DMI Vcp.
Enabled / Disabled
DMI Vcm Control
Enable or disable DMI Vcm.
Enabled / Disabled
DMI Link ASPM Control
Enable or disable the control of Active State Power Management on SA side of the
DMI Link.
L0sL1 / L0s / L1 / Disabled
DMI Extended Synch Control
Enable DMI Extended Synchronization.
Disabled / Enabled
DMI Gen 2
Enable or disable DMI Gen 2. Auto means Disabled for IVB A0 MB/DT and IVB B0
MB. Enabled for other CPUs.
Auto / Disabled / Enabled
