3.4.2.3 NB PCIe Configuration
Aptio Setup Utility --- Copyright © 2011 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Configure PEG0 B0:D1:F0
Gen1-Gen3
NB PCIe Configuration
PEG0I
PEG0 --- Gen X
PEG0 ASPM
Enable PEG
Not present
[Auto]
[Auto]
[Auto]
→←: Select screen
↑↓: Select item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
PEG0 --- Gen X
Configure PEG0 B0:D1:F0 Gen1-Gen3.
Auto / Gen1 / Gen2 / Gen3
PEG0 ASPM
Control ASPM support for the PEG: Device 1 Function 0. This has no effect if PEG
is not the currently active device.
Auto / Disabled / ASPM L0s / ASPM L1 / ASPM L0sL1
Enable PEG
Enable or disable the PEG.
Auto / Enabled / Disabled
