16
Motherboard Components
Connectors
1.Audio Jack(J5) 20. SPI TPM Header (ESPI TPM1)
2. VGA+ COM PORT (VGA_COM1)
21. Front USB3.2 Gen1 Header
(USB3_FPIO1)
3. VGA Header (FPIO_VGA3) 22. SGPIO Header (SATA1_SGPIO)
4. RJ45 LAN Port (LAN4)&USB2.0x2 23. SATA1-4-7
5. RJ45 LAN Port (LAN3) Dedicated IPMI
&USB3.2 Gen1 x2
24. SATA1-2-3
6. RJ45 LAN Ports (LAN1&LAN2) 25. Power Connector(PWR4)
7. ID LED Button (ID BTN) 26. Power Connector(PWR1)
8. PSMI Connector (PSMI_HD1) 27. Power Connector(PWR3)
9. M.2 Socket (M.2#1) 28. 4-pin FAN Connector (SYSFAN5)
10. POWER Button (POWER) 29. 4-pin FAN Connector (SYSFAN4)
11. RESET Button (REST) 30. 4-pin FAN Connector (SYSFAN3)
12. Front Panel Connector (SSI_FP) 31. CPU0_FAN(CPUFAN1)
13. Fan Connector for BB (FAN_FP) 32. Power Connector(PWR2)
14. ESPI DEBUG Header (J4) 33. Chassis Intrusion Header(INTR)
15. IPMB Connector (IPMB_HD1) 34. 4-pin FAN Connector (SYSFAN2)
16. COM2 Header (HD_COM2) 35. 4-pin FAN Connector (SYSFAN1)
17. SATA RAID Key (RAID KEY) 36. MCIO0 Connector (MCIO0)
18. BIOS DEBUG (BIOS_DBG1) 37. Front Audio Header (J6)
19. NVMe Hot Plug Function Connector (HDR_3)
Jumpers/ Headers
a. COM2_RX Jumper (J118) g. BIOS Advance Function Jumper(J5_PCH)
b. COM2_TX Jumper (J119) h. System Buzzer Jumper (J14)
c. BIOS Recovery Jumper (J1_PCH) i. BMC Remote Debug Jumper (J19)
d. PassWord Clear Jumper (J2_PCH) j. CPLD setup Jumper (J7)
e. ME Recovery Jumper (J3_PCH) k. BIOS S5 Flash Enable Jumper (J2)
f. MFG Mode Jumper (J4_PCH) l. System Reset Mode Jumper (J136)
PCIE Slots
A. PCI-e Gen5 x16 FH/FL (PCIE5) D. PCI-e Gen 5 x16 FH/FL (PCIE2)
B. PCI-e Gen5 x16 FH/FL (PCIE4) E. PCI-e Gen5 x16 FH/FL (PCIE1)
C. PCI-e Gen5 x8 FH/FL (PCIE3)
LEDs
i ME_LED (ME_LED)
iv PLD_HB_LED (D33)
ii HDD_LED1 (HDD_LED1) v BMC_HB_LED (D1_BMC)
iii IPMI_LED1 (IPMI_LED)
