TYAN S7010 - Page 13

13
http://www.tyan.com
Jumper/Connector Function
J44 Front Panel Connector
J17/J19 1394 Front Panel Header (black)
J27/J28 USB Front Panel Header (blue)
J8 COM2 Connector
J41 IPMB Connector
J45 Chassis Intrusion Header
J4 Intel HD Audio Header
J6 Specific Definition Audio Header
USB5 Type-A USB Connector
J1 CD_IN Connector
J35 PSMI Connector
J38 ICH SGPIO Header
J43 (BTO) SAS SGPIO Header
J46/J47/J48/J49/J50 8-pin 4096 Fan Connector
J9/J14/J39/J40/J42 4-pin Fan Connector
J7
BMC Reset Jumper
NC: Default
Pin 1-2 closed: Disable BMC
JP1
Clear CMOS Jumper
Pin 1-2 closed: Normal (Default)
Pin 2-3 closed: Clear
JP2/JP3
COM2 Switch Jumper
Pin 1-2 closed: SIO to COM2 (Default)
Pin 2-3 closed: BMC UART2 to COM2
JP4
Onboard 1394 Enable/Disable Jumper
Pin 1-2 closed: Enable (Default)
Pin 2-3 closed: Disable
