The following tables outline the suggested rules for populating memory.
Table 1 RDIMM population
Single Rank
Memory
DIMM C0 x x x x(*) x(*) x(*) x(*) x(*)
DIMM C1 x(*) x(*) x(*) x(*) x(*)
DIMM B0 x x x(*) x(*) x(*) x(*)
DIMM B1 x(*) x(*) x(*)
DIMM A0 x x(*) x(*)
DIMM A1 x(*)
Dual Rank
Memory
DIMM C0 x x x x(*) x(*) x(*) x(*) x(*)
DIMM C1 x(*) x(*) x(*) x(*) x(*)
DIMM B0 x x x(*) x(*) x(*) x(*)
DIMM B1 x(*) x(*) x(*)
DIMM A0 x x(*) x(*)
DIMM A1 x(*)
Quad Rank
Memory
DIMM C0 x(*) x(*) x(*) x(**) x(**) x(**) x(**) x(**)
DIMM C1 x(**) x(**) x(**) x(**) x(**)
DIMM B0 x(*) x(*) x(**) x(**) x(**) x(**)
DIMM B1 x(**) x(**) x(**)
DIMM A0 x(*) x(**) x(**)
DIMM A1 x(**)
x(*) 1066MHz
x(**) 800MHz
S7010 RDIMM population One DIMMs per Channel Two DIMMs per Channel
Max Memory combination
Single Rank Registered DIMMs
48GB(12x4GB DIMMs)
Dual Rank Registered DIMMs
96GB(12x8GB DIMMs)
Quad Rank Registered DIMMs
96GB(12x8GB DIMMs)
