3.2.2.1 SATA0/1/2/3/4/5 Sub-Menu
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
SATA0
Device: Not Detected
Type
LBA /Large Mode
Block (Multi-Sector Transfer)
PIO Mode
DMA Mode
S.M.A.R.T.
32 Bit Data Transfer
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Enabled]
Selects the type of device
connected to the system.
← → Select Screen
↑↓ Select Item
+/- Change Option
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
Feature Option Description
SATA0
Auto
Not Installed
CD/DVD
Type
ARMD
Selects the type of device connected to
the system.
Auto
LBA/Large Mode
Disabled
Auto: Enabled LBA Mode if the device
supports it and the device is not already
formatted with LBA Mode disabled.
Disabled: Disabled LBA Mode.
Auto
Block (Multi-Sector Transfer)
Disabled
Disabled: The Data transfer from and to
the device occurs one sector at a time.
Auto: The Data transfer from and to the
device occurs multiple sectors at a time
if the device supports it.
Auto
PIO Mode
0~4
(at 1 interval)
Selects the PIO Mode. Select Auto to
enhance hard disk performance by
optimizing the hard disk timing.
DMA Mode Auto
Selects DMA Mode.
Auto: Auto detected.
Auto
Disabled
S.M.A.R.T.
Enabled
S.M.A.R.T (Self-Monitoring Analysis
and Reporting Technology) is a utility
that monitors your disk status to predict
hard disk failure.
Enabled
32Bit Data Transfer
Disabled
Enables 32-bit to maximize the IDE
hard disk data transfer rate.
