TYAN S7010 - Page 49

49
http://www.tyan.com
3.2.4.1 – USB Mass Storage Device Configuration Sub-Menu
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
USB Mass Storage Device Configuration
USB Mass Storage Reset Delay
Device #1
Emulation Type
[20 Sec]
USB Flash Disk
[Auto]
Number of seconds POST
waits for the USB mass
storage device after start
unit command
← → Select Screen
↑↓ Select Item
+/- Change Option
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
Feature Option Description
USB Mass Storage Device Configuration
10 Sec
20 Sec
30 Sec
USB Mass Storage Reset
Delay
40 Sec
Number of seconds POST waits for the
USB mass storage device after the start
unit command
Device #1 Read only
Auto
Floppy
Forced FDD
Hard Disk
Emulation Type
CDROM
If Auto, USB devices less than 530 MB
will be emulated as Floppy and
remaining as hard drive. Forced FDD
option can be used to force a HDD
formatted drive to boot as FDD
(Ex. ZIP drive).
