Others Chassis intrusion detection / Watch Dog timer support
Onboard Chipset Onboard Aspeed AST2050
AST2050 IPMI Feature
IPMI 2.0 compliant baseboard management controller
(BMC) / Supports storage over IP and remote
platform-flash/ BIOS update / USB 2.0 virtual Hub
Server
Management
AST2050 iKVM
Feature
24bit High quality video compression / Dual 10/100
Mb/s MAC interfaces
Brand / ROM size AMI / 4MB
BIOS
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/PXE Boot / ACPI 2.0 power management /Power on
mode after power recovery / User-configurable H/W
monitoring / Auto-configurable of hard disk types /
Multiple boot options
Form Factor SSI EEB
Form Factor
Board Dimension 12"x13" (305x330mm)
Operation
System
OS supported list
Please visit our Web site for the latest OS supported
list.
FCC (Doc) Class B
CE (Doc) Yes
C-Tick Yes
Regulation
VCCI Yes
Operating Temp 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp - 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6 Complaint Yes
Motherboard (1) TYAN motherboard
Manual (1) User's manual / (1) Quick Ref. Guide
Installation CD (1) TYAN Installation CD
I/O Shield (1) I/O Shield
SATA (6) SATA signal cables
USB (1) USB bracket cable
Accessory
list
Cable
IEEE1394 (1) IEEE1394 bracket cable
Optional
accessories
Riser Card
M2083-RS, PCI-E x16 1U riser card (right) / M2061,
PCI-E x8 to PCI-X 1U riser card (left)
