(4) PCI-E Gen.2 x16 slots (w/ x16 link,
Sot#5,7 from 1st SR5690; Slot#1,3 from 2nd
SR5690)
(1) PCI-E Gen.2 x8 slot (w/ x4link from 2nd
SR5690, Slot#4)
PCI-E
(1) PCI-E Gen.2 x4 slot (w/x4 link from 2nd
SR5690, Slot#6)
Expansion
Slots
PCI (1) PCI 32-bit slots (Slot#2)
Recommended
Barebones /
Chassis
2U Chassis FT48
Port Q'ty 4
LAN
Controller (2) Intel 82574L / (1) Intel 82576EB
Connector
(2) Mini-SAS connectors (support 4
HDD’s/cable)
Controller LSI SAS2008 (for S8225WAGM4NRF only)
Speed 6.0 Gb/s
SAS
RAID RAID 0/1/1E/10 (LSI Integrated RAID)
Connector (6) SATA
Controller AMD SP5100
Speed 3.0 Gb/s
Storage
SATA
RAID RAID 0/1/10/5 (Promise Integrated RAID)
Connector type D-Sub 15-pin
Resolution 1600x1200@60Hz
Graphic
Chipset Aspeed AST2050
Onboard Chipset Realtek ALC262
Audio
Feature 2.1 channel
Port Q'ty (2) IEEE 1394 headers
Firewire
Chipset VIA VT6308P PCI Firewire controller
USB
(9) USB2.0 ports (4 at rear, 4 via cable, 1
Vertical [Type A] onboard)
COM (2) ports (1 at rear, 1 via cable)
SAS (2) Mini-SAS (4-in-1) connectors
VGA (1) D-Sub 15-pin VGA port
RJ-45 (4) GbE ports
Power
ATX12V / Universal 24-pin + 8-pin + 8-pin
power connectors
Input /Output
Front Panel (1) 2x12-pin SSI front panel header
