Chapter 1: Instruction
1.1 - Congratulations
You have purchased one of the most powerful server solutions. Based on the
AMD
®
SR5690 & SP5100 chipset, The TYAN
®
S8225 series motherboard is
designed to support 2 AMD
®
4-Core/6-Core Opteron™ 4100 series processors.
It is up to 128GB for RDDRIII and 32GB for UDDRIII .The memory interface
supports speed up to 1333MT/s.There are also 4 channels with 8 DDR3
DIMMs, providing a rich feature set and incredible performance. Leveraging
the advanced technology from AMD
®
, the TYAN
®
S8225 series is capable of
offering a scalable 32 and 64-bit computing environment with high-bandwidth
memory design and lightning-fast PCI-E Gen2 bus implementation.
The S8225 not only empowers you in today’s demanding IT environment but
also offers a smooth path for future application upgradeability. All of these rich
feature sets provides the S8225 with the power and flexibility to meet
demanding requirements for today’s IT environments.
The TYAN S8225 series is designed around several different configurations
which are detailed in the following 1.2 Hardware Specification section:
1.2 - Hardware Specifications
TYAN S8225
Supported CPU
Series
AMD 4-Core/6-Core Opteron™ 4100 Series
Processors
Socket Type / Q'ty C32 1207-pin / (2)
Average CPU
Power (ACP)
wattage
75W
Processor
System Bus Up to 6.4 GT/s Hyper-Transport link support
Chipset (2) AMD SR5690 + SP5100
Chipset
Super I/O Winbond W83627
DIMM slot Qty (4)+(4) DIMM slots
DIMM Type / Speed U/RDDR3 & LV RDDR3, 800/1066/1333MHz
Capacity
supports up to 128GB RDIMM at 800MHz or
32GB UDIMM at 1066MHz
Memory channel 2 Channels per CPU
Memory
Memory voltage 1.35V/ 1.5V
