8.3 Reex Mark Dimensions
Labelswithreexmarks Endlessmaterialwithreexmarks
Fig.15 Reexmarkdimensions
Dim. Designation Dim. in mm
A Label distance > 2
AZ Distance between print zones >2
L Widthofreexmark > 5
M Heightofreexmark 3 - 10
X Distance mark - material edge -53 - ±0
Z Distance virtual label front edge - actual label front edge
Adjust software settings
0 up to A /
recomm. : 0
Reexmarksmustbeonthebacksideofthematerial(liner).
Labelsensorforreexmarksonthetopsideonrequest.
Specicationisvalidforblackmarks.
Recognition of colored marks may fail.  Preliminary tests are needed.
•
•
•
•
Table10 Reexmarkdimensions
