2 Installation
2.2 Unpacking and Setting-up the Printer
Check label printer for damage which may have occurred during transport.
Set up printer on a level surface.
Remove foam transportation safeguards near the printhead.
Check delivery for completeness.
Contents of delivery:
Label printer
Power cables
USB cable
Documentation
Print Easy and Wintotal Demo on CD-ROM
Documentation on CD-ROM
i
Notice!
Please keep the original packaging in case the printer must be returned.
!
Attention!
The device and printing materials will be damaged by moisture and wetness.
Set up label printers only in dry locations protected from splash water.
2.3 Connecting the Device
Thestandardavailableinterfacesandconnectorsareshowningure3.
2.3.1 Connecting to the Power Supply
The printer is equipped with a wide area power unit. The device can be operated with a supply voltage of
230 V~/50 Hz or 115 V~/60 Hz without adjustment.
Check that the device is switched off.
Plugthepowercableintothepowerconnectionsocket(20).
Plug the power cable into a grounded socket.
2.3.2 Connecting to a Computer or Computer Network
!
Attention!
Inadequate or no grounding can cause malfunctions during operations.
Ensure that all computers and cables connected to the label printer are grounded.
Connect the label printer to a computer or network by a suitable cable.
2.4 Switching on the Device
When all connections have been made:
Switchtheprinteronatthepowerswitch(19).
The printer performs a system test, and then shows the system status readyinthedisplay(8).
If an error occurs during the system test, the symbol and type of error are displayed.




•
•
•
•
•
•
