19 Power switch
20 Power connection jack
21 Slot for PC Card Type II
22 Slot for CompactFlash memory card
23 Ethernet 10/100 Base-T
24 2 USB master ports for keyboard,
scanner or service key
25 USB high-speed slave port
26 Serial RS-232 C port
Fig. 3 Connections
