PowerSeries - PC1616/PC1808/PC1832/PC1864
Special Installer Instructions
Section [898] Wireless Enrollment
Refer to Section 2.13 WT5500 Wireless Enrollment Procedure for details.
Section [899] Template Programming
Selecting [][8] [Installer Code] [899] displays the current 5-digit template programming code. Refer to Section 3.1 Template Programming on
page 8 for programming details. Refer to Appendix C - Template Programming for a detailed description of available templates and corresponding 5
digit codes.
Section [900]: Panel Version Displayed
Only available with the PK/RFK/WT5500 or PTK5507 keypads. The system will display the version of the control panel (for example, [0470] indicates
panel version 4.70).
Section [901]: Installer Walk Test
The system will turn Installer Walk Test ON. The Ready, Armed and Trouble LED’s will flash rapidly while the test is active. Every time a zone is vio-
lated the system will activate the bell output for two seconds and log the event to the event buffer. To turn Installer Walk Test OFF enter Section [901]
again. The system automatically terminates the test of there is no zone activity for 15 minutes.
Section [902]: Module Supervision Reset
All modules are automatically detected within one minute after being connected to the Keybus. Enter Section [902] to clear detected modules if a module
is removed, if PC5108 jumpers are changed, or if a keypads slot assignments are programmed. The system will rescan the Keybus to determine which
modules are connected.
Section [903]: View Module Supervision
The keypad will display the modules detected by the system by turning on the associated zone light (LED keypads), flashing the numbers (fixed-message
LCD keypads) or displaying the modules detected in plain language (programmable LCD keypads). Refer to the chart below:
Section [904]: Wireless Placement Test
Enter Section [904] followed by the 2-digit number of the wireless zone to test. When a wireless signal is received from the selected transmitter, the sys-
tem will indicate the location as Good or Bad as follows:
Good:One bell squawk, 1 keypad beep, keypad zone light [1] ON
Bad:Three bell squawks, 3 keypad beeps, keypad zone light [3] ON
Press [#] to exit when testing is complete. Enter the 2-digit zone number for the next wireless device to test or press [#] to return to standard programming.
Section [989]: Default Master Code
Enter Section [989][Installer Code] to default the Master Code to the factory defaults.
Section [990]: Installer Lockout Enable
Enter Section [990][Installer Code][990] to enable the Installer Lockout feature. A hardware default cannot be performed when the Installer Lockout
feature is ON. In addition, the system will chatter the line seizure relay 10 times if the panel is powered up to indicate the feature is ON.
Section [991]: Installer Lockout Disable
Enter Section [991][Installer Code][991] to turn the Installer Lockout feature OFF.
This feature requires a PK55xx or RFK55xx series keypad, v.1.1 or higher.
Indicator Light
(Zone)
Module
[01] to [08]
[09] to [14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[22]
[24]
[26] to [29]
Keypad in Slot #1 to #8
PC5108 Zone Expander #1 to #6
PC5100 Module
PC5108 Zone Expander #7
RF Receiver
PC5208
PC5204 Module
PC5400 Module
PC59xx Module
Alternate Communicator
Escort5580 or Escort5580TC
PC5200 #1 to #4
