Template Programming
62
Appendix C: Template Programming
Template programming allows quick programming of the minimum functions required for basic operation. The below tables are used to determine the
desired template to be used ( for information on performing template programming see Section 4 – Programming Descriptions). Each digit represents 1
of the template sections listed below. The option number selected for each digit will make up the 5 digit template programming code.
Digit 1 selects Zone 1-8 definition options.
Digit 2 selects system EOL configuration options.
Digit 3 selects panel communications options.
Digit 4 selects reporting code configurations
,  indicates included, Blank indicates default setting, indicates disabled
Common Group
Option Zn1 Zn2 Zn3 Zn4 Zn5 Zn6 Zn7 Zn8 1 Delay 1
1 13334444 2 Delay 2
2 13355558 3 Instant
3 13355557 4 Interior
4 11333333 5 Interior Stay/Away
5 13365555 6 Delayed Stay/Away
6 13365558 7 Delayed 24-Hour Fire
Refer to Section 4 for Zone definition details 8 Standard 24-Hour Fire
Option [013] Opt 1 [013] Opt 2
1NC loops ON OFF
2SEOL OFF OFF
3DEOL OFF ON
Op# Phone Line 1 Programming Section Phone Line 2 Programming Section
1 Disabled [380] Opt 1 OFF Disabled [380] Opt 1 OFF
2 SIA automatic Reporting Codes enabled [350] 1st Phone # [04]
[380] Opt 1 ON
[381] Opt 3 OFF
SIA automatic Reporting Codes enabled [350] 2nd Phone #
[XX]
3 Contact ID Reporting Codes enabled [350] 1st Phone # [03]
[380] Opt 1 ON
[381] Opt 7 OFF
SIA automatic Reporting Codes enabled [350] 2nd Phone #
[XX]
4 SIA automatic Reporting Codes enabled [350] 1st Phone #[04]
[380] Opt 1 ON
[381] Opt 3 OFF
Residential Dial Enabled [350] 2nd Phone # [06]
5 Contact ID Reporting Codes enabled [350] 1st Phone # [03]
[380] Opt 1 ON
Opt 7 OFF
Residential Dial Enabled [350] 2nd Phone # [06]
6 Contact ID Reporting Codes enabled [350] 1st Phone # [03]
[380] Opt 1 ON
[381] Opt 7 OFF
Contact ID Reporting Codes Enabled [350] 2nd Phone # [03]
Option
Common
Group
Selected
Troubles
Openings/
Closings
Zone
Restorals
DLS/Installer
Lead In/Out
1 
2   
3 
4    
5  
6  
7   
8 
Description Phone 1 Phone 2 Sections
Set all Reporting Codes to automatic [320] - [349], [601] - [608] FF
Alarm/Restore call directions enabled  [351][1] ON, [2] OFF
Tamper/Restore Call directions disabled [359][1] OFF, [2] OFF
Opening/Closing Call directions disabled [367][1] OFF, [2] OFF
Maintenance Call Directions enabled  [375][1] ON, [2] OFF
Test Transmission Call directions disabled [376][1] OFF, [2] OFF
