5.2 To Silence the fire alarm
sounders:
• Turn the Access Controls Keyswitch on the
repeater door to position “1”.
• Press the Silence Alarms/Resound button once
only.
• The fire alarm sounders will become silent.
• The General Fire LED and the Zone Fire LED
will become steady.
• Set the Access Controls Keyswitch back to
position “0” to lock the controls.
5.3 To Resound the fire alarm
sounders after they have been silenced:
• Turn the Access Controls Keyswitch on
the repeater door to position “1”.
• Press the Silence Alarms/Resound button
once only.
• Set the Access Controls Keyswitch back to
position “0” to lock the controls.
5.4 To Reset the panel & repeater(s)
from a Fire Alarm:
• After the fire has been extinguished, turn the
Access Controls Keyswitch on the repeater
door to position “1”.
• Press the Reset button (the Sounders may need
to be silenced first, depending on
configuration).
• The General Fire LED and the Zone Fire LED
will clear.
• Set the Access Controls Keyswitch back to
position “0” to lock the controls.
5.5 To operate the fire alarm
sounders in Manual Fire Alarm /Muster
Mode:
• Turn the Access Controls Keyswitch on the
repeater door to position “1”.
• Press the Manual fire alarm/Muster button.
• The Manual fire alarm/Muster LED will light
and the repeater buzzer will operate.
• All fire alarm sounders will operate.
• Press the Silence/Resound Alarm button to
silence the fire alarm sounders and clear the
Manual fire alarm/Muster LED.
• Set the Access Controls Keyswitch back to
position “0” to lock the controls.
5.6 If a fault is detected:
• The panel buzzer will sound.
• The General Fault LED will flash.
• One or more fault LEDs will flash; identifying
which element of the system is faulty.
• When the fault is corrected the fault indication
will clear automatically unless the panel is
configured to latched fault mode – in which
case, operating the Reset button will clear the
fault indication.
5.7 To Silence the Buzzer:
• Press the Silence Buzzer button.
• The Silence Buzzer button LED will light.
• The buzzer will silence.
5.8 System Fault Indication:
In the event of a complete repeater failure, a System
Fault will be indicated on the repeater:
• The SYSTEM FAULT and GENERAL
FAULT LED illuminate. All other LEDs will
be extinguished.
• The internal buzzer will sound continuously.
Warning: The Repeater is completely inactive
apart from the operation of Muster alarms if
configured.
User Actions:
• Silence the buzzer on the panel.
• Call your service engineer immediately.
• Record the event in the system log book.
