3.2 User Controls
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
01
ZONE LOCATION
FIRE
POWER SUPPLY ON
POWER SUPPLY FAULT
SYSTEM FAULT
GENERAL FAULT
EARTH FAULT
FUSE FAILED
REPEATER FAULT
FAULT OUTPUT FAULT/DISABLED
SOUNDER FAULT/DISABLED
SOUNDER TEST
FIRE PROTECTION FAULT/DISABLED
FIRE OUTPUT ACTIVE
FIRE OUTPUT FAULT/DISABLED
BUZZER
SILENCE
RESET
ENABLE
DISABLE
TEST
TEST DISPLAY
ALARMS
RESOUND
SELECT
ON/OFF
SELECT
SILENCE/
ALARM
MUSTER
FIRE
1. THE RED ZONE INDICATOR
WILL PULSE SHOWING THE
LOCATION OF THE FIRE.
2. CARRY OUT THE
REQUIRED FIRE DRILL.
3. TO SILENCE ALARMS
PRESS SILENCE ALARMS.
4. TO RESET FROM THE FIRE
CONDITION PRESS RESET.
FAULT
1. DETERMINE THE CAUSE OF
THE FAULT.
2. PRESS SILENCE BUZZER.
3. CALL YOUR SERVICE
ENGINEER.
SYSTEM FAULT
THE PANEL IS INOPERATIVE.
ARRANGE FOR ALTERNATIVE
FIRE DETECTION MEASURES.
DISABLEMENT AND TEST
1. PRESS SELECT ON/OFF.
THE LED WILL ILLUMINATE.
2. SELECT THE ZONE OR
OUTPUT USING
↑ AND ↓. THE
FAULT LED WILL PULSE.
3. PRESS DISABLE OR TEST.
4. TO RE-ENABLE, SELECT
THE ZONE OR OUTPUT AND
PRESS ENABLE.
OVERRIDE
DELAY
MODEL:
T1216
C.I.E. PRODUCTION PERIOD: 1
www.tycomarine.com
EN54-2: 1997
EN54-4: 1997
KM95744
Switch
Description
Functionality Button Availability
Manual Fire Alarm
or Muster
[Configuration
option]
Manual Fire Alarm: Operates all sounders continuously and lights the Manual fire
alarm/Muster LED adjacent the button until the silence button is operated
Muster: Operate all sounders in the Muster mode and lights Muster LED
When controls are unlocked
Silence/Resound
Alarms
Following a fire alarm condition, 1st operation stops sounders. The General Fire
LED and the Zonal fire LED will change from flashing to steady. 2nd operation
restarts the previously silenced sounders
When controls are unlocked
Reset
Clears the panel display, resets the zones, outputs and operates the reset relay.
When controls are unlocked
and [if silence before reset is configured]
alarms silence switch has been operated.
Silence Buzzer
Press to stop the buzzer sounding in fire or fault conditions.
When controls are locked or unlocked
Delay Override
Overrides the delay when delay is running, turning the delay mode and the LED
off. All delayed outputs will operate immediately.
When the panel is in the fire condition and
the delay is running.
Select On/Off
Enables the User select feature for selection of zones or outputs via Select ↑
Select ↓ for disablement/re-enablement.
When controls are unlocked
Test Display
Press to illuminate all LEDs on the display and operate the buzzer. All indications
remain active for approx 5 seconds after button release.
When controls are locked or unlocked
Enable
Press to clear the disablement or test condition on a zone or output selected via
the User Select feature.
When controls are unlocked, the Select
switch has been operated and a zone or
output has been selected
1] Press to disable a zone or output selected via the User Select feature. LED is lit
whilst any disablement is active
1] As above.
Disable
2] Press to view delay configuration of sounders, Fire and Fire Protection outputs. 2] When controls are unlocked.
Test
Press to initiate the One Man Test on sounders or zones as selected via the User
Select feature. LED lit whilst test mode is active.
As above.
1] Used to scroll the cursor indication through the zone and output fault LEDs on
the display to select a zone or output for disablement, or test. [LED illuminated
when Select Mode is active]
1] When controls are unlocked and the
Select switch has been operated.
Select ↑ Select ↓
2] Used to adjust the brightness of the display LEDs [Press Test Display and ↑ to
increase or Test Display and ↓ to decrease]
2] When controls are unlocked
Access Controls Keyswitch:
0 – Controls Locked
1 – Controls Unlocked
